Lexuma XScreen Portable Touch Monitor

Quick Guide

Lexuma XScreen is compatible with different devices. In the following passage, you can find the connection method of different devices with XScreen.

XScreen portable monitor support Type-C and HDMI connection and support charging though Type-C cable.

Lexuma XScreen portable monitor quick guide different connection method portable screen Type-C HDMI connection ports

The HDMI connection port is for the data signal only. The two Type-C connection ports are using for different purposes: the upper one is for the data signal, the lower one is for power supply ONLY. Finally, the micro connection port is for OTG keyboard, mouse, etc.



1. Connect with Laptop (Type-C Connection)

What you need:

1) Type-C to Type-C cable

2) A power adapter or Power Bank with Type-C cable for charging (when necessary)

Before you connect your laptop with XScreen, you need to check whether your laptop supports Type-C data output. You can check the devices with Type-C data output here.

Turn on XScreen and connect your laptop with XScreen through a Type-C to Type-C cable. Make sure you are using the right Type-C connection port(Refer to the picture below). Then, you can enjoy dual monitors with touch screen function.

Further setup on screen mirroring or dual-screen, please refer to our setup blog.

Lexuma XScreen portable monitor quick guide different connection method portable screen Type-C HDMI connection with laptops

2. Connect with Laptop (HDMI Connection)

What you need:

1) HDMI cable

2) USB to Type-C Cable (for touch screen function)

3) A power adapter or Power Bank with Type-C cable for charging (when necessary)

If your computer is not able to connect the external monitor with Type-C cable, you can use HDMI cable for connection. First, turn on XScreen and plug in an HDMI cable and connect it with your computer and XScreen. After that, you need to plug in a USB to Type-C cable for the touch screen function. If you don’t connect a USB to Type-C cable with your computer and XScreen, you cannot use the touch screen function.

Further setup on screen mirroring or dual-screen, please refer to our setup blog.





3. Connect with Mobile Phone (Type-C connection)

What you need:

1) Type-C cable

2) A power adapter or Power Bank with Type-C cable for charging (when necessary)

Some of the smartphones are able to connect with XScreen through a Type-C cable. If you are not sure whether your smartphone has Type-C date output, you may check here. Simply connect your smartphone and XScreen with a Type-C to Type-C cable, then you can use your mobile phone for work or entertainment on XScreen.





4. Connect with mobile phone (HDMI Connection)

What you need:

1) Type-C to HDMI / Lightning to HDMI converter

2) HDMI Cable

3) A power adapter or Power Bank with Type-C cable for charging (when necessary)

If your smartphone is able to support HDMI data output, you need to get a Type-C to HDMI or Lightning to HDMI converter for connection. Then, you can use the HDMI cable for connecting your smartphone and XScreen.

Lexuma XScreen portable monitor quick guide different connection method portable screen Type-C HDMI connection lightning to HDMI converter


5. Connect with Switch (Type-C connection)

What you need:

1) Type-C to Type-C cable

2) A power adapter or Power Bank with Type-C cable for charging (when necessary)

First, turn on XScreen and Switch, connect them with a Type-C to Type-C cable. It is better to have a power adapter or power bank with Type-C cable for charging. It can ensure XScreen has enough battery for gaming.





5. Connect with PS4/Switch (HDMI connection)

What you need:

1) HDMI to Mini HDMI cable

2) A power adapter or Power Bank with Type-C cable for charging (when necessary)

3) Switch docking for Switch Connection

You can use HDMI for connecting PS4 or Switch. Prepare an HDMI to Mini HDMI cable and connect Switch or PS4 with XScreen. Besides, you need a power adapter for charging up XScreen.

Lexuma XScreen portable monitor quick guide different connection method portable screen Type-C HDMI PS4Lexuma XScreen portable monitor quick guide different connection method portable screen Type-C HDMI Switch

6. Connect with iPhone/iPad (adaptor connection)

What you need:

1) Lightning to HDMI Adaptor

2) Power bank for power up the adaptor

3) USB to Lightning cable for charging

4) HDMI to Mini HDMI cable

5) A power adapter or Power Bank with Type-C cable for charging (when necessary)

XScreen is also support iPhone and iPad connection. You need to get an Lightning to HDMI convertor for connection even your iPhone or iPad has a Type-C connection port. You can only use the HDMI cable for connecting iPhone/iPad with XScreen. Remember you also need to power up the adapter for video signal.
